SAHYADRI

AUTO SOURCE CHANGE OVER WITH CURRENT LIMITER (THREE PHASE WITH NEUTRAL)

FEATURES :

• High Speed Microcontroller based design
• Precise and more accurate.
• Base plate mounting.
• In built SMPS for low power consumption.
• Status Indication through LED’s
• Fabricated Box

TECHNICAL SPECIFICATIONS :

• Suitable for three Phase with neutral
• No.of poles: Phase + Neutral
• Rated Current: Load EB Side 20A, 25A, 32A, 40A, 63A
• Rated Current: Load DG Side: 20A, 25A, 32A, 40A & 63A (Factory set)
• Time interval from EB to DG: After input stable in DG - after 3 Sec
• Sec Time interval from DG to EB : Load will switch on after 3 Sec
• Protection to change over : Contactor protection
• Surface mounting
• Enclosure : Fabricated Box
• Optional feature: Auto reset available

AUTO SOURCE CHANGE OVER WITH CURRENT LIMITER (SINGLE PHASE)

FEATURES :

• High Speed Microcontroller based design
• Precise and more accurate.
• Din rail mounting
• In built SMPS for low power consumption
• Status Indication through LED’s
• Under voltage / over voltage cutoff facility

TECHNICAL SPECIFICATIONS :

• Suitable for Single Phase from 175 to 270 V AC 50 Hz
• No.of Poles : 1 Phase + Neutral
• Rated Current: Load DG Side: 1A to 20A (Factory Set)
• interval from EB to DG: After input stable in DG - after 2 Sec
• Time interval from EB to DG: After input stable in DG - after 3 Sec
• Time interval from DG to EB : Instantaneous
• Protection to change over : Break Neutral before breaking phase
• Protection under voltage : 150V AC
• Protection over voltage : 270V AC
• Enclosure: ABS plastic Mounting Din rail
• Dimension : 75 x 110 x 60 mm

AUTO SOURCE CHANGEOVER WITH CURRENT LIMITER (ACCL):

3 Ph & 1 Ph is an indispensable tool to automatic power distribution, protect expensive Generators and prevent fatal risks - The power instability in developing countries along with the inefficient rationalized power distribution creates a need for the alternative source of power, to back up the utility supply, and hence, most of the commercial and residential complexes set-up alternate power sources, such as gensets, to provide efficient back-up for their power needs.

However, when the Generator is used user should not over load the Generator by putting too many loads like AC cooling system Water Heater, Washing machine & others activities, and it is required protect from critical damage to the expensive equipment’s & Generator.

3 Ph & 1 Ph ACCL, a fully automatic high precision micro controller based ‘Source Change Over’ device, which also has current limiting function an offers easy and ‘ controllable’ change over between main power supply and generator supply. And mainly it will protects the Generator from over load. When there is over load to Generator, ACCL will wait of 3 sec then it switches off the LOAD for 6 sec, then once again switch on the load for 3 sec observe it for whether the load is below the said load, if load is more than switch off / on cycle will continue for 5 cycles, then it will go to lockout mode & makes the load is permanently off. Further to switch ON the Load, it required to press the Reset button(3Ph) / OFF & ON the follower MCB (1 Ph).
